Lavina · (Discontinued)
At a glance
- SKU
- L3213REB
- Vendor
- Lavina
- Grinding width
- 32 in (814 mm)
- Motor
- 20 hp (15 kW)
- Grinding pressure
- 552 to 858 lb
Documents
WarrantyCovered by the manufacturer warranty. Latux stocks parts and provides technical support for every machine we sell.
Technical helpParts, service and warranty claims through your Latux rep. Mon to Fri, 8 to 5 EST.Contact a pro
Lavina · Discontinued Equipment
Lavina 32 Elite Remote-Controlled Electric Floor Grinder (Discontinued)
Discontinued. Lavina no longer manufactures the 32 Elite. Its replacement is the Lavina 31R S7 (L31RS7). The specs below stay here for reference and for service on machines already in the field.The Lavina 32 Elite is a 32 inch three-phase remote grinder with three operating modes, remote, self-propelled, and manual. A touchscreen and a dust-proof planetary drive bring big-machine production to large commercial floors.A 20 hp motor drives the head...
Key performance
32 inGrinding widthMore floor per pass
20 hp electricPowerNo exhaust indoors
3 × 13.2 inPlanetary headsEven, flat scratch pattern
552-858 lbGrinding pressureBites into hard concrete
Best forWarehouses and large slabs
Runs on3 phase, 200-240 V, 60 ATell us your power setup when you request a quote.
What it does
Surface prep for coatings
Coating and glue removal
Polishing
Leveling
$34,490.00
Manufacturer's Suggested Retail Price. Equipment is sold by quote.
Title Request a Quote
Request a quote
Authorized dealer. Talk to your Latux rep for your best price, freight, and lead time.
Prefer to talk now? (800) 413-1427
Request a quote
Lavina 32 Elite Remote-Controlled Electric Floor Grinder (Discontinued)
A Latux rep will send your price, freight, and lead time.
Prefer to talk now? (800) 413-1427
Pairs with
Lavina 31R S7 Remote-Controlled Electric Floor Grinder (L31RS7)Sold by quote
›
Lavina V32E Electric Dust ExtractorSold by quote
›
- Authorized dealer
- Parts and service
- Freight quoted to your site
- Tech support Mon-Fri
- Operator walkthrough included
- Financing available
- Ask about a demo
At a glance
Lavina 32 Elite Remote-Controlled Electric Floor Grinder (Discontinued)
Discontinued
Lavina no longer manufactures the 32 Elite. Its replacement is the Lavina 31R S7 (L31RS7), a 31 inch, 20 hp remote-controlled electric grinder with a sealed S7 head. The 32 Elite specs stay below for reference and for service on machines already in the field. See the Lavina 31R S7
The Lavina 32 Elite is a 32 inch three-phase electric floor grinder, a 20 hp planetary floor grinder with remote, self-propelled, and manual modes for big-machine production. It is built for large commercial floors where a touchscreen and off-deck control keep wide passes consistent.
32"
GRINDING WIDTH
Wide production pass
20
HP MOTOR
Three-phase power
858
LB PRESSURE
Down to the aggregate
1607
LB WEIGHT
Self-propelled deck
What makes it work
Built for large commercial floors
Three operating modes
Drive it by remote, let it self-propel, or run it manually, whichever the slab calls for.
Big three-phase power
A 20 hp motor on three-phase 200 to 240 V, with a 380 to 480 V high-voltage option, brings big-machine production.
Touchscreen control
A touchscreen shows load and machine data so the operator dials in the cut from off the deck.
Heavy tunable pressure
Grinding pressure runs 552 to 858 lb with head speed 400 to 650 rpm for aggressive removal or a controlled polish.
MOTOR
| Motor | 20 hp (15 kW) |
| Power | 3 phase, 200 to 240 V, 60 A (80 A breaker, 45 kW generator). High-voltage option 380 to 480 V, 32 A |
| Head speed | 400 to 650 rpm |
GRINDING
| Grinding width | 32 in (814 mm) |
| Heads | 3 planetary, 13.2 in (335 mm) each, counter-clockwise |
| Grinding pressure | 552 to 858 lb |
| Modes | Remote, self-propelled, manual |
| Water | 12 gal, two-valve |
| Tooling | Lavina quick-change plates |
DIMENSIONS
| Weight | 1,607 lb (729 kg) |
Job-ready
Complete your setup.
What this machine works with on the job. Add tooling to your cart or get a quote on matching equipment.
Works with
Pairs with a Lavina electric dust extractor sized to the 32 inch head and Latux metal-bond and PCD tooling. Run the grinder, a matched extractor, and the right tooling as one high-output system on large commercial floors.
Shop the setup
Lavina V32E Electric Dust Extractor
$11,990.00Quote
What power does it need?
Three-phase 200 to 240 V at 60 A, or a 380 to 480 V high-voltage option. Plan an 80 A breaker or a 45 kW generator.
Three modes?
Yes. Drive it by remote, let it self-propel, or run it manually.
How much grinding pressure does it apply?
552 to 858 pounds with head speed 400 to 650 rpm, tuned from aggressive removal to a fine polish.
What dust extractor should I pair with it?
A Lavina electric extractor sized to the 32 inch head, plus Latux tooling on the quick-change plates.
How do I buy it, and what about freight?
The 32 Elite is sold by quote. Call or message your Latux rep for current price, freight, and lead time. The MSRP shown is for reference.
